Bộ lưu điện UPS CyberPower OLS6000E

Model

OLS6000E

Capacity (VA/W)

6000VA / 5400W

Typology

Online (Double Conversion)

Energy-Saving Technology

Yes, ECO Mode Efficiency > 96%

Input

Input Type

Terminal Block

Frequency Range

45 ~ 65Hz

Output

UPS Outlets (Numbers)

Terminal Block

On Battery Output Voltage

Pure Sine Wave at 208, 220, 230, 240 Vac (Configurable)

On Battery Output Voltage Distortion (@Nominal Battery Voltage)

< 2%(Linear Load), <5%(Non-Linear Load)

On Battery Output Frequency

50 Hz / 60 Hz (Auto-Sensing or Configurable) ± 0.5%

Transfer Time (Typical)

0 ms

Overload Protection

Line Mode: 10 minutes minimum,then transfer to bypass @105%150%; 1 second minimum then transfer to bypass@Load>170%

Battery Mode: 2 minutes minimum,then shutdown @105%150%

Short Circuit Protection

UPS Output Cut off Immediately or Circuit Breaker Protection

Surge Protection and Filtering

Surge Protection

Yes

DSL/ Phone/ Fax/ Modem protection

No

Battery

Sealed Maintenance Free Lead Acid Battery

(20) 12V / 7AH

Typical Recharge Time

7 Hours

Runtimes

Half load-Full load (mins)

15/5

Status Indication

Indicators

Power On, Line Mode, Battery Mode, Bypass Mode, ECO Mode,C/F Mode, Fault, Replace Battery

Audible Alarms

Battery Mode, Battery Low, Overload, UPS Fault, Replace Battery

Communication

Power Management Software

PowerPanel® Business Edition

Management

Self-Test

Yes

Auto-Charge/ Auto-Restart

Yes

Auto-Overload Recovery

Yes

Cold Start (DC Start)

Yes

Connectivity Ports

(1) Serial Port (RS232), (1) USB Port, (1) EPO/ROO

SNMP/ HTTP Capable

Optional

Dimensions

708 x 260 x 550 mm

Weight

70 kg
