Camera DS-2CD2420F-IW |
|
|
Image Sensor |
1/2.8' Progressive Scan CMOS |
|
Signal System |
PAL/NTSC |
|
Min. Illumination |
0.01Lux @(F1.2,AGC ON), 0 Lux with IR |
|
0.028Lux @(F2.0,AGC ON), 0 Lux with IR |
|
|
Shutter time |
1/3 s to 1/100,000 s |
|
Lens |
4mm@ F2.0, Angle of view: 85° |
|
(2.8mm, 6mm optional) |
|
|
Lens Mount |
M12 |
|
Day& Night |
IR cut filter with auto switch |
|
Wide Dynamic Range |
Digital WDR |
|
Digital noise reduction |
3D DNR |
|
Compression Standard |
|
|
Video Compression |
H.264/MJPEG |
|
H.264 code profile |
Main Profile |
|
Video bit rate |
32Kbps~8Mbps |
|
Audio Compression |
G.711/G.722.1/G.726/MP2L2 |
|
Audio bit rate |
64Kbps(G.711) /16Kbps(G.722.1)/16Kbps(G.726) /32-128Kbps(MP2L2) |
|
Image |
|
|
Max. Image Resolution |
1920 x 1080 |
|
Frame Rate |
50Hz: 25fps(1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720) |
|
60Hz: 30fps(1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720) |
|
|
Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
|
BLC |
Yes, zone configurable |
|
ROI |
support |
|
3D DNR |
support |
|
Network |
|
|
Network Storage |
NAS (Support NFS,SMB/CIFS) |
|
Alarm Trigger |
Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
|
Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS, DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP, IGMP,802.1X,QoS,IPv6,Bonjour |
|
Security |
One-key reset, flash-prevention, dual streams, heartbeat, mirror, password protection, privacy |
|
mask, Watermark, IP address filtering, Anonymous access |
|
|
System Compatibility |
ONVIF, PSIA, CGI, ISAPI |
|
Interface |
|
|
Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
|
Alarm Input |
1 |
|
Alarm Output |
1 |
|
On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
|
Wi-Fi Specification (-W) |
|
|
Wireless Standards |
IEEE802.11b, 802.11g, 802.11n |
|
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
|
Channel Bandwidth |
20/40MHz Support |
|
Modulation Mode |
802.11b: CCK, QPSK, BPSK |
|
802.11g/n: OFDM |
|
|
Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
|
Transmit Power |
11b: 17±1.5dBm @ 11Mbps |
|
11g: 14±1.5dBm @ 54Mbps |
|
|
11n: 12.5±1.5dBm |
|
|
Receive Sensitivity |
11b: -90dBm @ 11Mbps (Typical) |
|
11g: -75dBm @ 54Mpbs (Typical) |
|
|
11n: -74dBm (Typical) |
|
|
Transmission Rate |
11b: 11Mbps |
|
11g: 54Mbps |
|
|
11n: up to 150Mbps |
|
|
Wireless Range |
50m(depend on environment) |
|
Protocols |
IEEE802.11b, 802.11g, 802.11n |
|
General |
|
|
Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) |
|
Humidity 95% or less (non-condensing) |
|
|
Power Supply |
12 V DC ± 10%, PoE (802.3at) |
|
Power Consumption |
MAX. 4.5W |
|
IR Range |
10 meters |
|
PIR |
Angle: 80° |
|
Dimensions |
72.3×89.9×131.3 |
|
Weight |
400g (0.88lbs) |
