Cisco 867VAE Secure router with VDSL2/ADSL2+ over POTS CISCO867VAE-K9
| Feature | Description |
|---|---|
| DRAM |
● 256 MB (nonwireless routers) ● 512 MB (wireless routers) ● 512MB ( For C867VAE, C866VAE-K9, C867VAE-K9) |
| Flash memory |
● 56 MB for Cisco 866VAE-K9 and 867VAE-K9 Secure Routers ● 64 MB for Cisco 866VAE and 867VAE Base Routers ● 128 MB for C866VAE-W-K9 and C867VAE-W-K9 Secure Wireless Routers ● 128MB for C867VAE, C866VAE-K9, C867VAE-K9 Routers |
| WAN |
● Gigabit Ethernet or ● Multimode VDSL2 and ADSL2/2+ over ISDN or ● Multimode VDSL2 and ADSL2/2+ over basic telephone service |
| LAN |
● Base routers: Managed 4-port 10/100BASE-T with autosensing MDI/MDX ● Secure routers: 1 GE + 4-port 10/100BASE-T with autosensing MDI/MDX ● Secure Wireless routers: 2 GE + 3-port 10/100BASE-T with autosensing MDI/MDX ● Secure Wireless routers: 802.11n 2.4 GHz ETSI/FCC compliant |
| Console or auxiliary port | RJ-45 |
| Power over Ethernet | 1-port 15W PoE on C867VAE-POE-W-A-K9 SKU only |
| USB |
● One USB 2.0 ● USB port can be used for: ◦ USB flash memory 128 MB (MEMUSB-128FT), 256 MB (MEMUSB-256FT), and 1 GB (MEMUSB 1024FT) ◦ Cisco IOS Software boot from USB Note: USB 2.0 port cannot be used for connecting external devices or as a console other than those specified at https://www.cisco.com/en/US/prod/collateral/modules/ps6247/product_data_sheet0900aecd80232473.html. |
| Physical dimensions and weight | Product dimensions, base routers (part numbers CISCO866VAE and CISCO867VAE):
● H x W x D = 1.75 x 9.5 x 9.0 in. (4.45 x 24.1 x 22.9 cm), 1 rack unit (1 RU) Product dimensions, secure routers (CISCO866VAE-K9 and CISCO867VAE-K9):● H x W x D = 1.75 x 9.5 x 9.0 in. (4.45 x 24.1 x 22.9 cm), 1 RU ● Weight: 5.5 lb (2.5 kg) maximum |
| Power | Product power specifications:
● AC input voltage: 100 to 240 VAC ● Frequency: 50 to 60 Hz ● Maximum output power: 60W ● Output voltages: 12 VDC |
| Approvals and compliance | Emissions:
● 47 CFR Part 15: 2006 ● CISPR22: 2005 ● EN300386: V1.3.3: 2005 ● EN55022: 2006 ● EN61000-3-2: 2000 [Inc amd 1 and 2] ● EN61000-3-3: 1995 [+ amd 1: 2001] ● ICES-003 Issue 4: 2004 ● KN 22: 2005 ● VCCI: V-3/2006.04 Immunity:● CISPR24: 1997 [+ amd 1 and 2] ● EN55024: 1998 [+ amd 1 and 2] ● EN61000: 4-3, 4-6 ● AS/NZS 3548 ● CFR 47 Part 15 Class B ● EN55022 Class B |
| Environmental operating range |
● Nonoperating temperature: -4 to 149°F (-20 to 65°C) ● Nonoperating humidity: 5 to 95% relative humidity (noncondensing) ● Nonoperating altitude: 0 to 15,000 ft (0 to 4570m) ● Operating temperature ◦ At sea level: 32 to 104°F (0 to 40°C) ◦ Up 10,000 ft: 32 to 77°F (0 to 25°C) ◦ Derating 2.7°F/10,000 ft (1.5°C/1000 ft) ● Operating humidity: 10 to 85% relative humidity (noncondensing) ● Operating altitude: 0 to 10,000 ft (0 to 3000m) |
DSL Specifications
Tables 8 through 11 list the DSL feature specifications and DSLAM interoperability support for the Cisco 860VAE Series Routers. For more information and details about DSLAM and line-card interoperability, please refer to the following document: What Is Cisco ISR and ISR G2 xDSL Interoperability?
The Cisco 860VAE Series interoperability should be on par with the Cisco 880VA Series ISRs.
Table 8. DSL Feature Specifications
| DSL Specifications | |
| Multimode DSL (VDSL2 and ADSL2 and 2+) |
● Broadcom chipset ● Dying gasp (Note: Dying Gasp is not assured on Annex M) ● IEEE 802.1q VLAN tagging VDSL2:● ITU G.993.2 (VDSL2) ● 997 and 998 band plans ● VDSL2 profiles: 8a, 8b, 8c, 8d, 12a, 12b, and 17a ● U0 band support (25–276 kHz) ● Ethernet PTM mode only based on IEEE 802.3ah 64/65 octet encapsulation ● DELT diagnostics mode ADSL2/2+:● ADSL over basic telephone service with Annex A and ISDN Annex B ITU G. 992.1 (ADSL), G.992.3 (ADSL2), and G.992.5 (ADSL2+) ● ADSL2+ over basic telephone service Annex M (for extended upstream bandwidth) for G.992.3 (ADSL2) and G.992.5 (ADSL2+) Note: Annex M performance is not optimal over Annex A SKUs.● G.994.1 ITU G.hs Handshake Protocol ● Reach-extended ADSL2 (G.922.3) Annex L for increased performance on loop lengths greater than 16,000 feet from central office ● T1.413 ANSI ADSL DMT issue 2 ● DSL Forum TR-067 and TR-100 performance compliant ● Inpulse Noise Protection (INP) with Extended Framing Parameters ● Downstream Power Back Off (DPBO) ● Fixed Firmware solution for General deployments. No ability to upgrade the Firmware on the 860VAE models (applicable to all non-Wifi models) |
Table 9. VDSL2 over ISDN and Basic Telephone Service DSLAM Interoperability for Cisco 866VAE and Cisco 867VAE
| DSLAM | VDSL2 over ISDN and Basic Telephone Service Line-Card Chipset |
| ZTE 9806 | Broadcom |
| Alcatel ISAM 7302 | Ikanos |
| Alcatel ISAM 7302 | Conexant |
| Huawei 5603 | Broadcom |
Table 10. ADSL over ISDN DSLAM Interoperability for Cisco 866VAE
| DSLAM | ADSL2/2+ over ISDN Line-Card Chipset |
|---|---|
| Alcatel ASAM 7300 | Broadcom |
| ECI Hi-Focus 480 | Infineon |
| Ericsson ECN320 | Broadcom |
| Siemens HiX 5300 | Infineon |
Table 11. ADSL over Basic Telephone Service DSLAM Interoperability for Cisco 867VAE
| DSLAM | ADSL2/2+ over Basic Telephone Service Line-Card Chipset |
| Alcatel ASAM 7300 | Broadcom |
| Alcatel ISAM 7302 | Broadcom |
| Ericsson EDA2.1 | Broadcom |
| ECI Hi-Focus 480 | Infineon |
| Fujitsu FDX Hub 1000 | Infineon |
| Fujitsu FDX Hub 1000 | Texas Instruments |
| Huawei MA5600 | Conexant |
| Lucent Stinger | Conexant |
| Nokia D500 | Globespan |
