Đầu ghi hình camera IP 32 kênh HIKVISION DS-9632NI-I16

Model

DS-9632NI-I16

Video/ Audio Input

IP video input

32 channel

Two-way audio input

1-ch, RCA (2.0 Vp-p, 1kΩ)

Network

Incoming bandwidth

320Mbps or 200Mbps (when RAID is enabled)

Outgoing bandwidth

256Mpbs or 200Mbps (when RAID is enabled)

Remote connection

128

Video/Audio Output

HDMI/VGA output

2-ch, resolution: HMDI1/ VGA1: HDMI1: 4K (3840 x 2160)/ 60Hz

4K (3840 x 2160)/ 30Hz, 2K (2560 x 1440)/ 60Hz, 1920 x 1080p/ 60Hz, 1600 x 1200/ 60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/ 60Hz

VGA1: 2K (2560 x 1440)/60Hz, 1920 x 1080p/ 60Hz, 1600 x 1200/60Hz, 1280 x 1024/ 60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz

HDMI2/VGA2: 1920 x 1080p/60Hz, 1280 x 1024/ 60Hz, 1280 x 720/60Hz, 1024 x 768/ 60Hz

Recording Resolution

12MP/ 8MP/ 6MP/ 5MP/ 4MP/ 3MP/ 1080p/ UXGA/ 720p/ VGA/ 4CIF/ DCIF/ 2CIF/ CIF/ QCIF

Audio Output

2-ch, RCA (2.0Vp-p, 1KΩ)

Synchronous Playback

16-ch

Decoding

Video format

H.265, H.264+, H.264, MPEG4

Live view / Playback

12MP/ 8MP/ 6MP/ 5MP/ 4MP/ 3MP/ 1080p/ UXGA/ 720p/ VGA/ 4CIF/ DCIF/ 2CIF/ CIF/ QCIF

Capability

4-ch@4K, 16-ch@1080p

Hard Disk

SATA

16 SATA interfaces for 16 HDDs

Interface Type

1 eSATA interface

Capacity

Up to 6TB capacity for each HDD

Disk array

Array type

RAID0, RAID1, RAID5, RAID6, RAID10

Number of array

5

External Interface

Network Interface

2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces

Serial Interface

RS-232, RS-485, Keyboard

USB Interface

Front panel: 2 x USB 2.0

Rear panel: 1 x USB 3.0

General

Power supply

100 ~ 240VAC, 50/60Hz

Power

≤ 45W

Chassis

19-inch rack-mounted 2U chassis

Dimensions

445 x 496 x 146mm

Weight

≤ 12.5 kg
