Thiết bị mạng Switch HP 8P 1920S 8G JL380A

I/O ports and slots

8 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
Physical characteristics

Dimensions:

10(w) x 6.28(d) x 1.73(h) in

(25.4 x 15.95 x 4.39 cm) (1U height)


Weight: 1.81 lb (0.82 kg)
Memory and processor ARM Cortex-A9 @ 400 MHz, 256 MB SDRAM, 64 MB flash; packet buffer: 1.5 MB
Mounting and enclosure wall, desktop and under table mounting
Performance

100 Mb Latency < 7.0 µs
1000 Mb Latency < 2.4 µs
Throughput up to 11.9 Mpps
Switching capacity: 16 Gbps
MAC address table size: 8,000 entries
Environment

Operating temperature: 32°F to 104°F (0°C to 40°C)
Operating relative humidity: 5% to 95%, noncondensing
Nonoperating/Storage temperature:-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage relative humidity:15% to 95% @ 140°F (60°C)
Altitude: up to 10,000 ft (3 km)
Acoustic: Pressure: 0 dB No Fan
Electrical characteristics

Frequency: 50/60 Hz
Voltage: 100 - 240 VAC, rated
Maximum power rating: 9.5 W
Idle power: 8.2 W
Safety UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60825-1
Emissions

VCCI Class A; CNS 13438; ICES-003 Issue 5 Class A; FCC CFR 47 Part 15, Class A; EN 55032: 2015/CISPR-32
Management Web browser
