Đầu ghi hình camera IP 32 kênh Ultra HD 4K H.265 HIKVISION iDS-9632NXI-I8/16S

Model

iDS-9632NXI-I8/16S

Video/Audio Input

Two-way audio input

1-ch, RCA (2.0 Vp-p, 1kΩ)

IP video input

32-ch

Network

Incoming bandwidth

320Mbps or 200Mbps(when RAID is enabled)

Outgoing bandwidth

256Mpbs or 200Mbps(when RAID is enabled)

Video/Audio Output

HDMI/VGA output

2-ch, resolution:

HMDI1: 4K (3840 x 2160)/ 60Hz,

4K (3840 x 2160)/30Hz, 2K (2560 x 1440)/ 60Hz, 1920 x 1080p/ 60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz

VGA1: 2K (2560 x 1440)/ 60Hz, 1920 x 1080p/ 60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/ 60Hz, 1024 x 768/ 60Hz

HDMI2/VGA2: 1920 x 1080p/60Hz, 1280 x 1024/ 60Hz, 1280 x 720/60Hz, 1024 x 768/ 60Hz

CVBS Output

1-ch, BNC (1.0Vp-p, 75Ω)

Resolution: 704 x 576(PAL); 704 x 480(NTSC)

Synchronous Playback

16-ch

Decoding

Capability

8-ch @ 1080p

Live view / Playback

12MP/ 8MP/ 6MP/ 5MP/ 4MP/ 3MP/ 1080p/ UXGA/ 720p/ VGA/ 4CIF/ DCIF/ 2CIF/ CIF/ QCIF

Hard Disk

eSATA

1 eSATA interface

SATA

8 SATA interfaces for 8 HDDs

Capacity

Up to 8TB capacity for each HDD

Disk array

Array type

RAID0, RAID1, RAID5, RAID6, RAID10

Number of array

4

External Interface

Network Interface

2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces

Serial Interface

RS-232, RS-485, Keyboard

USB Interface

Front panel: 2 x USB 2.0

Rear panel: 1 x USB 3.0

Alarm In

16-ch

Alarm Out

4-ch

PoE

Max. Power

200W

General

Power Supply

100 to 240VAC, 50 to 60 Hz

Chassis

19-inch rack-mounted 2U chassis

Dimensions

445 x 470 x 90 mm

Weight

≤ 10 kg
